风华贴片排容

片式排容系列（C-ARRAY SERIES）
一、优点 FEATURE
※节约空间: 可以节省高达50%的PCB 空间位置， 提高装配密度
Space saving: CA can save 50% space of the PC board and improve the assembling density.
※更高的体积比容: 安装一块CA 等于安装4 块0603 片容，减少安装次数，提高安装效率
Provide more capacitance per volumetric area: Efficiently use the side margins and thickness. Promoting
mounting efficiency. One chip of CA equals to four chips of 0603 type capacitor. So it can reduce times of
picking and placing.
※降低成本: 减少放置的次数；缩短生产时间；减少设备管理费用；减少PCB 费用
Cost saving: Reduce times for picking and placing, reduce manufacturing time, reduce the cost for manage the
equipments and reduce the cost of PCB.
※安装简易: 可进行SMT 编带包装，由贴片机高速贴片
Easy to picking and placing: SMT package, easy to mounting.
※提高线路板工作效率: 可以减少印刷的线路。提高线路板的运转速度，提高工作效率
Improve the working efficiency of the printed board: Reduce the amount of printed circuits and promote the
working speed of the printed circuit.
二、用途 APPLICATIONS
※适用于对元器件空间要求严格的PCB，如手提电脑、PDA、无绳电话
Applied in PCB which require strictly about space speed, such as notebook computer, PDA and portable
telephone, etc.
※特别适用于输入、输出接口电路

CA is best suitable to use in I/O interface circuit.
